API Specification 5CT; API Specification 5B

API 5CT Production Tubing

Specify API 5CT production tubing by edition, exact grade, outside diameter and nominal weight or wall, length range, end finish and connection. Include drift, inspection documents, well-service requirements, quantities, destination port and required delivery date for quotation.

Request a Quote WhatsApp Contact Technical Sales

PRODUCT SPECIFICATIONS

KEY SPECIFICATIONS

Grade: Exact grade under the governing standard; confirm on quotation/PO.
Standard: API Specification 5CT; API Specification 5B
Manufacturing process: Permitted manufacturing route under the governing standard; confirm on quotation/PO.
Outer diameter: Outside diameter or nominal pipe size under the governing standard; confirm on quotation/PO.
Wall thickness: Wall thickness, schedule, or nominal weight under the governing standard; confirm on quotation/PO.

Technical classification

Material / substrate: Carbon Steel
Form: Tube
Application: Oil & Gas

Product specifications

Send grade, standard, dimensions, and delivery requirements for a matched product quotation.

Product specifications
Property	Value
Product identity
Product	API 5CT Production Tubing
Grade	Exact grade under the governing standard; confirm on quotation/PO.
Material	Carbon Steel
Product form	Tube
Standards and classification
Standard	API Specification 5CT; API Specification 5B
Dimensions
Outer diameter	Outside diameter or nominal pipe size under the governing standard; confirm on quotation/PO.
Wall thickness	Wall thickness, schedule, or nominal weight under the governing standard; confirm on quotation/PO.
Process and connections
Manufacturing process	Permitted manufacturing route under the governing standard; confirm on quotation/PO.

Overview

API tubing is an oil-country tubular goods product used in well completion and production strings. It should be ordered as tubing under API Specification 5CT, not as structural pipe, line pipe, or casing. The RFQ should identify the API 5CT edition, grade, outside diameter and nominal weight or wall, length range, end finish, upset type, and connection. API EUE and NUE are tubing connection references; proprietary connections require the connection owner's exact designation and acceptance criteria. Buyers should also state drift requirements, hydrostatic or non-destructive inspection scope, marking, thread protection, quantity, and destination. Grade, size, connection, and inspection availability remain subject to technical review against the complete order. Service conditions such as sour service require additional project specifications and material qualification.

Product scope

Identify the exact tubing grade and connection
Compare dimensions, weight and length on the same order basis
Agree drift, inspection and thread protection before purchase

Applications

Production tubing strings specified for an oil or gas well
Replacement tubing matched to the approved completion specification

Surface options

Surface treatment and storage protection specified by the order
Thread compound and protectors matched to the agreed connection

Processing & form

End finish and upset type to the accepted order
Drift, hydrostatic testing and NDT scope defined by the governing specification

Packing, inspection & delivery documents

Include packing, material certificate and inspection requirements so costs and delivery arrangements can be reviewed together.

Packing & delivery

Export packing options

State thread protectors, storage protection, package quantities, maximum bundle or crate weight and lifting limits. Include the destination port and required delivery date. Confirm packing and delivery terms before order acceptance.

Quality assurance

Quality documents

Specify material identification, dimensional checks, applicable thread inspection, acceptance criteria and the required inspection certificate. Agree traceability, witness points and document availability in the quotation and purchase order.

Export packing & loading evidence

Representative export packing and loading evidence. Final packing follows the approved order.

FAQ

What is needed to quote API 5CT tubing?

State edition, exact grade, OD and nominal weight or wall, length range, upset type, end finish and connection. Add drift and inspection requirements, well service, quantities and destination. Confirm the offered combination against the complete purchase specification.

Can EUE and NUE tubing be interchanged?

EUE and NUE identify different tubing end and connection arrangements. Specify the connection required by the completion design. A matching nominal size does not approve substitution; changes require the buyer’s technical acceptance.

Does an API 5CT grade alone confirm sour-service suitability?

Provide the well service specification, operating environment and any additional material qualification or testing requirements. A grade name or reference to API 5CT alone does not establish suitability for a particular well.

Which inspection documents should the order specify?

Identify the required inspection certificate, material and heat identification, dimensional results and applicable thread inspection records. Add product-specific tests, acceptance criteria and witness points. Confirm the scope and document availability before placing the order.

Request an OCTG quotation

Send the pipe or coupling specification, connection details, quantities, inspection requirements and destination port.
